| Inside Groove Digital Calipers with Cylindrical Contacts |
|
|
| Features : |
Flat measuring surfaces or spherical measuring surfaces are optional
Can measure the narrow inside groove in the hole..
Special-made orders require following specifications:
1.The diameter of the hole
2.The distance between the groove and the orifice
3.The width of the groove
4.The depth of any side of the grooves
5.The shape of the groove bottom |
|
| |
| Specifications : |
| |
Measuring
Range |
Order No. |
Resolution |
Limit
Error |
L |
a |
b |
c |
d |
e |
Φ |
| |
24-150mm |
113-301 |
0.01mm |
±0.04mm |
250 |
30 |
3 |
7 |
16 |
5 |
2 |
| |
35-150mm |
113-301-1 |
0.01mm |
±0.05mm |
250 |
60 |
3 |
11.5 |
16 |
6 |
2 |
| |
50-150mm |
113-301-2 |
0.01mm |
±0.05mm |
260 |
90 |
4 |
17 |
20 |
8 |
3 |
| |
25-200mm |
113-302 |
0.01mm |
±0.04mm |
310 |
40 |
3 |
7.5 |
16 |
5 |
2 |
| |
40-200mm |
113-302-1 |
0.01mm |
±0.05mm |
310 |
70 |
3 |
13 |
16 |
7 |
3 |
| |
60-200mm |
113-302-2 |
0.01mm |
±0.05mm |
310 |
100 |
3 |
20 |
20 |
10 |
3 |
| |
30-300mm |
113-303 |
0.01mm |
±0.05mm |
410 |
50 |
3 |
10 |
16 |
5 |
2 |
| |
50-300mm |
113-303-1 |
0.01mm |
±0.06mm |
410 |
80 |
3 |
17 |
16 |
8 |
3 |
| |
60-300mm |
113-303-2 |
0.01mm |
±0.06mm |
410 |
110 |
3 |
20 |
20 |
10 |
3 |
| |
40-500mm |
113-305 |
0.01mm |
±0.06mm |
680 |
90 |
3 |
15 |
24 |
5 |
3 |
| |
60-500mm |
113-305-1 |
0.01mm |
±0.07mm |
680 |
120 |
3 |
20 |
24 |
10 |
3 |
| |
80-500mm |
113-305-2 |
0.01mm |
±0.07mm |
680 |
150 |
3 |
24 |
24 |
16 |
3 |
|
| |
